Bakery Powder Mixing, Conveying And Packing System
Shanghai Dahe Packaging Machinery Co., Ltd. is one of the leading manufacturers and suppliers of bakery powder mixing, conveying and packing system in China. With abundant experience, we warmly welcome you to buy durable bakery powder mixing, conveying and packing system for sale here from our factory. Quality products and reasonable price are available.
Bakery Powder Mixing, Conveying And Packing System
|
25kg Bag UV Tunnel Big Bag Sterilizer This machine is composed of 5 segments: 1.Blowing and cleaning, 2-3-4 Ultraviolet sterilization,5. 2 Transition Blow & cleaning: designed with 8 air outlets, 3 on top and 3 at bottom, each on the 2 sides, and equipped with blowing machine 3 Ultraviolet sterilization: each segment contains 8 pieces Quartz ultraviolet germicidal lamps, 3 on top and 3 at bottom, and each on the 2 sides. 4 The stainless steel cover up, down, left and right are easy to remove for maintain.Stainless steel chain to move the bags forward 5 Fully stainless steel structure and carbon steel 6 electroplating rotation shafts 7 Dust collector is not included |
|
| 2 Bag dump station and Sifter Applications: This system can be used for the unpacking, discharging and sieving of middle and small bags in pharmaceutical, chemical and food industry, especially for the discharging and sieving of materials with poor flow ability. Dust can be avoided during the unpacking process with the help of the dust collecting fan. System Structure: Bag dump station: This system is composed of manual unloading bin, pressure-proof unloading platform, discharging hopper, vibrating sifter, filtering system, blow back airbag, vibrating motor, etc. Working Process: The bag is manually opened and put into this system when materials in the bag are required to be discharged into the next process. The dust in the discharging process can be collected by the dust collecting filter. The vibrating screen mesh (safety screen mesh) can block the oversized and foreign materials while qualified materials can be smoothly discharged to the next process. |
 |
|
3 Horizontal Ribbon Mixer Ribbon Mixer consists of horizontal U shape mixing vessel, drive system and ribbon agitator. The mixing element is combined with inner and outer double helical ribbon agitator. The outer ribbon moves materials into center direction and inner ribbon moves the materials in opposition direction to shape radially and laterally movement. Finally, the material will be discharged at center discharge valve. Ribbon Blender is an efficient and versatile blending machine for mixing of dry granules & powders homogeneously. Various materials can be mixed in ribbon mixer through a gentle way, especially in food material mixing. The Feature 1 Made in 304SS and Meet GMP stard. 2 Tank was full welding and Polished . There is no dead end . 3 The Mixing time per Bacth is 10-15 mins. One Hour Can work 3-4 batches 4 The machine can mix different rate powder and granule. 5 During Working , The machine Can Spray Some liquid into the granule and Powder(optional) 6 At the top of the Machine , One Safety gate for stop falling other items 7 Weighing checking system(Optional) |
 |
|
4 Jar or Bottle Powder Filling Line Unsramble machine-- Capping machine --Induction sealing machine --Labelling Machine |
|
|
5 Can Filling Line Can Sorting--Uv Sterizilzation -scoop Filling --Powder Filling --Can seamer- Platic lid capping --Can collection |
|
Hot Tags: bakery powder mixing, conveying and packing system, China bakery powder mixing, conveying and packing system manufacturers, suppliers, factory, Powder packing machine, , Powder Mixing system, ribbon blender line, paddle blender, ribbon mixer machine price
