Ribbon Blender And Paddle Blender

Leading Ribbon Blender And Paddle Blender Manufacturer

DAHEPACK is a forward-thinking, design-driven manufacturer of ribbon blender and paddle blender. Our products include high-quality ribbon blenders, double ribbon agitator ribbon mixer, dry granular & powders ribbon blender, etc. We have led the way in innovative design, manufacturing and servicing.

First 12 3 4 5 6 7 Last 1/34

Why Choose Us

Rich Experience

With 25+ years manufacturing and sales experience as top powder filling solution provider in China. With more than two decades of expertise, experience and innovation, serving global milk powder, bakery and food powder factories.

Fast Delivery

Complete packaging to ensure products quality, and transport to the destination in the first time. All products will be inspected strictly before packing.

Quality Assurance

Our machines correspond to the following standards like:CE / ISO9000. We have 100% quality guarantee to customers.

Good Service

Our technical specialists can evaluate existing products and develop innovative solutions for your unique applications.

Types of Ribbon Blender And Paddle Blender

Double Ribbon Agitator Ribbon Mixer

The double ribbon mixer design moves solids in two directions simultaneously and also rotationally to provide the mixing action.

Horizontal Trough-shaped Ribbon Blender

Horizontal Trough-shaped Ribbon mixers are industrial machines used for blending dry powders, granules, and other bulk materials.

Stainless Steel Construction Ribbon Blender

These mixers are commonly used in food, chemical, pharmaceutical, and cosmetic industries and can handle various materials.

Twin Paddle Shaft Blender

The twin paddle shaft mixer consists of paddles mounted on separate shafts in a 'w' shaped mixing vessel.

Food Grade Paddle Blender

A Food Grade Paddle Blender is a specialized mixing machine designed for efficiently blending food ingredients while maintaining high hygiene standards.

Ribbon Blender Technical Parameters

Model	DH-JD-200	DH-JD-300	DH-JD-500	DH-JD-1000	DH-JD-1500	DH-JD-2000
Effective Volume	200L	300L	500L	1000L	1500L	2000L
Fully Volume	284L	404L	692L	1286L	1835L	2475L
Turning Speed	46rpm	46rpm	46rpm	46rpm	46rpm	46rpm
Total Weight	250kg	350kg	500kg	700kg	1000kg	1300kg
Total Power	4kw	5.5kw	7.5kw	11kw	15kw	22kw
Length(TL)	1370	1550	1773	2394	2715	3080
Width(TW)	834	970	1100	1320	1397	1625
Height(TH)	1647	1655	1855	2187	2313	2453
Length(BL)	888	1044	1219	1500	1800	2000
Width(BW)	554	614	754	900	970	1068
Height(BH)	637	697	835	1050	1155	1274
Radius(R)	277	307	377	450	485	534
Power Supply	3P AC208-415V 50/60Hz

Video

Paddle Mixer Technical Parameters

Main technical data
Mode	DHCL150	DHCL-300	DHCL-500	DHCL-1000	DHCL-1500	DHCL-2000
Effective volume	150L	300L	500L	1000L	1500L	2000L
Fully volume	185L	400L	680L	1280L	1820L	2450L
Loading rate	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Turning speed	53 rmp	53 rpm	45 rpm	45 rpm	39 rpm	39 rpm
Total weight	680 kg	980 kg	1600 kg	2800 kg	3800 kg	5000 kg
Total power	4kw	5.5kw	7.5kw	11kw	15kw	18.5kw
Length(mm)	2900	3240	3400	3600	3900	4200
Width(mm)	960	1040	1150	1380	1560	1800
Height(mm)	1200	1450	1500	1690	1840	1950
Power supply	3P AD208-415V 50/60HZ
Note	All metal structure: SS 304 ,full welded and polished

Video

Advantages of Ribbon Blender

Uniform Mixing: One of the primary advantages of ribbon blenders is their ability to ensure uniform mixing of ingredients.

Efficiency and Speed: Ribbon blenders are known for their efficiency and speed. The design allows for rapid mixing, which can significantly reduce production times.

Versatility: Ribbon blenders are incredibly versatile and can handle a wide range of materials, from powders to pastes.

Cost-Effectiveness: The efficiency of a ribbon blenders reduces labor costs and increases productivity, further improving your return on investment.

Easy to Clean and Maintain: Ribbon blenders are designed with easy cleaning in mind. Many models feature removable components and easy-access areas that make cleaning and maintenance a breeze.

Advantages of Paddle Blender

Uniform Mixing: Paddle blenders provide good mixing uniformity, ensuring that all components are evenly distributed throughout the mixture.

Versatility: They can handle a wide range of materials, including powders, granules, and materials with varying particle sizes.

Customization: The design and configuration of the paddles can be tailored to meet specific blending requirements, making them suitable for various applications.

Ease of Operation: Paddle blenders are relatively easy to operate and maintain, and many models offer variable speed controls for precise blending.

Efficient Mixing: They provide efficient blending within relatively short mixing times, reducing processing times and improving production efficiency.

Uses of Ribbon Blenders

Food Industry

Blending flour, spices, baking mixes, powdered milk, and other dry ingredients.

Pharmaceuticals

Mixing active ingredients with excipients to produce tablets and capsules.

Chemicals

Combining dry chemicals for products like detergents, fertilizers, and plastics.

Cosmetics

Preparing powdered makeup products such as foundations and eyeshadow.

Uses Of Paddle Blenders

Food Industry: Mixing nuts, cereals, dried fruits, and other delicate items without breaking them.

Incorporating liquids into dry mixes to create dough, batters, or coatings.

Pharmaceuticals: Blending sensitive compounds that high shear forces could damage.

Animal Feed and Pet Food: Combining ingredients while maintaining the integrity of the components.

Chemical Processing: Mixing powders with liquids to form slurries or pastes.

The Major Difference of Paddle Blender and Ribbon Blender

The major difference between paddle blender and ribbon blender is that the ribbon blender is suitable for large batch of bulk materials no need conveyor; but the paddle mixer is more suitable for small batch or large batch but normally need conveyor. In addition, both types of mixers can mix materials of different sizes, shapes and densities.

Use Requirements

Do size your blender properly.

Do not replace your existing ribbon blender's motor with a larger one to handle a new higher-density formulation, at least not without consulting your blender manufacturer.

Do use a variable frequency drive (VFD) to allow slow start under full load and protect the system against a spike in start-up torque.

Do not bottom filling your blender. Optimal mixing in a ribbon blender requires enough batch material - equivalent to at least 30-40% of the rated volumetric capacity.

Do inform your blender supplier if you intend to remove the agitator after every batch.

Do consider a paddle-style agitator instead of a ribbon if blending fragile materials.

Do equip your ribbon blender with an extrusion screw if mixing thick pastes and other viscous applications.

After use, the blender should be cleaned and stored in a dry and ventilated place.

Order Process

Inquiry

You can contact our professional technicians and explain your requirements in detail. We will provide you with what you need according to your requirements.

Add to Quote and Submit

We will provide a detailed quotation based on the products you need, including machine specifications, pricing, delivery time and payment terms.

Place an Order and Pay

Once confirmed, we will place the order with you by signing a purchase contract. Pay the corresponding deposit.

Production and Quality Control

After receiving the payment information of the order, we start production, ensuring that all components meet the quality standards.

Packaging and Shipping

Once everything is ready for shipping, the machine will be carefully packed and shipped with protective materials! Just sit back and wait for your order!

Other Services

Warranty Service: One year warranty against shipping date ,our engineer can be at your site for commissioning and installation or via whatsapp/ skype/ wechat to provide remote technical support.

Delivery Time: Single machines order 20-40days, Production line order 60-90days.

Payment Terms: 30% T/T deposit and 70% T/T before delivery or you can come to inspect the machines before delivery then make final payment.

Payment Methods: We can offer payment method like west union, T/T, L/C, paypal, credit card, wechat pay, Alipay.

Shipping: In order to offering better service,we have operated with multiple shipping companies like Fedex, DHL, DUP, UPS, EMS etc. We sure that you can choose the most suitable one.

Package: We will package it in Plywood Box. And it can prevent the machine from being spoiled.

FAQ

Q: Are you factory or trading company?

A: We are factory located in shanghai china with 20 years manufacturing experience.

Q: What machines you can make?

A: Auger filler, screw and vacuum feeder, Ribbon and paddle mixer, Vertical form fill and seal powder packaging machine, Complete Powder bottling/canning Production line etc.

Q: Can i visit your factory and send our team for training before order delivery?

A: Yes, sure! Welcome to visit us and get a training or make FAT!

Q: How to reach you?

A: By Cell Phone& Wechat& Whatsapp 0086-186-2117-5508 Or By Email:international2@dahepack.com.

Q: What is the mechanism of ribbon blender?

A: The mixing medium often consists of inner and outer helical ribbons that are designed to move material both inwards and outwards. The external helical ribbons pull product from the sides of the mixer into the middle and the internal ribbons push the product back to the sides.

Q: How fast is a ribbon blender?

A: Ribbon blenders consist of a U-shaped horizontal trough and a solid agitator shaft mounted with spokes that support outer and inner helical blades called ribbons. Powered by a gearmotor drive, the agitator rotates and produces a peripheral speed of up to approximately 300 fpm.

Q: How to load a ribbon blender?

A: To be cost effective ribbon blenders are loaded to the top of the agitator. Lesser ribbon blender loading will allow proportionately faster mixing. The minimum loading is about 40% of the maximum which is required to keep both the inner and outer ribbon in the product zone.

Q: How does a paddle blenders work?

A: The shaft is driven by a motor to which paddles are connected. The rotational motion which helps in mixing the fluid with the paddle shaft arrangement. Two bladed and four bladed paddle are common. They turn at slow to moderate speed in the centre of the vessel and push the liquid rapidly and tangentially.
