Shanghai Dahe Packaging Machinery Co., Ltd. is one of the leading manufacturers and suppliers of ribbon blender mixer machine 100 kg 150 kg 200 kg 250 kg 300 kg 500 kg 1000 kg in China. With abundant experience, we warmly welcome you to buy durable ribbon blender mixer machine 100 kg 150 kg 200 kg 250 kg 300 kg 500 kg 1000 kg for sale here from our factory. Quality products and reasonable price are available.
Features:
Commonly used in the food, chemical, and Pharma industries for quick mixing of dry granular & powders
Heavy gauge 304 stainless steel construction with welded end plates
Standard packing shaft sealing thus avoiding any type of contamination
Blending area comes with hinged cover
Operator safety grid in stainless steel with safety sensor standard
Butterfly valve for product discharge at bottom centre
Complete stainless steel construction (no paint)
Direct drive heavy duty helicoil drive system
All welds ground smooth for high quality uniform finish
Power: 220, 3 phase, 50/60 Hz. is most common (other voltage available upon request)
Mixing Capacity (kg/lbs): 175/350, 250/500, 400/800, 700/1400, 1060/2120, 1400/2800
Mixing Capacity (liter): 200, 300, 500, 1000, 1500, 2000
Horsepower: 5, 7.5, 10, 15, 20, 30
Power: 220 VAC & 550 VAC
Main Technical Data
|
Model |
DH-JD-200 |
DH-JD-300 |
DH-JD-500 |
DH-JD-1000 |
DH-JD-1500 |
DH-JD-2000 |
|
Effective Volume |
200L |
300L |
500L |
1000L |
1500L |
2000L |
|
Fully Volume |
284L |
404L |
692L |
1286L |
1835L |
2475L |
|
Turning Speed |
46rpm |
46rpm |
46rpm |
46rpm |
46rpm |
46rpm |
|
Total Weight |
250kg |
350kg |
500kg |
700kg |
1000kg |
1300kg |
|
Total Power |
4kw |
5.5kw |
7.5kw |
11kw |
15kw |
22kw |
|
Length(TL) |
1370 |
1550 |
1773 |
2394 |
2715 |
3080 |
|
Width(TW) |
834 |
970 |
1100 |
1320 |
1397 |
1625 |
|
Height(TH) |
1647 |
1655 |
1855 |
2187 |
2313 |
2453 |
|
Length(BL) |
888 |
1044 |
1219 |
1500 |
1800 |
2000 |
|
Width(BW) |
554 |
614 |
754 |
900 |
970 |
1068 |
|
Height(BH) |
637 |
697 |
835 |
1050 |
1155 |
1274 |
|
Radius(R) |
277 |
307 |
377 |
450 |
485 |
534 |
|
Power Supply |
3P AC208-415V 50/60Hz |
|||||
Main features
Ribbon Blenders consist of U shape horizontal trough and specially fabricated ribbon agitator.
Effective mixing load(40%-80%)
High mixing speed and short uniform time. Mixing speed is around 5-15min
All stainless steel 304 material
Full Mirror polished mixing tank inside, as well as ribbon and shaft
Safety switch, safety grid
Discharge gate can be manual or pneumatically operated for direct filling in bags or dumping into storage bin.
Frequently asked questions:
Q1:Are you factory or trading company?
A: We are factory located in shanghai china with 20 years manufacturing experience.
Q2: What machines you can make?
A: Auger filler, screw and vacuum feeder, Ribbon and paddle mixer, Vertical form fill and seal powder packaging machine, Complete Powder bottling/canning Production line etc.
Q3: Can i visit your factory and send our team for training before order delivery?
A: Yes, sure! Welcome to visit us and get a training or make FAT!
Q4: What's your warranty and after-sale service?
A: One year warranty against shipping date ,our engineer can be at your site for commissioning and installation or via whatsapp/skype/wechat to provide remote technical support.
Q5 : What is the payment term?
A: 30% T/T deposit and 70% T/T before delivery or you can come to inspect the machines before delivery then make final payment!
Q6:How long is the delivery time?
A: Single machines order 20-40days, Production line order 60-90days.
Q7:How to reach you?
A:By Cell Phone& Wechat& Whatsapp 0086-186-2117-5508
Or By Email:international2@dahepack.com
