Chicken Seasoing Powder Can Filling Machine
Shanghai Dahe Packaging Machinery Co., Ltd. is one of the leading manufacturers and suppliers of chicken seasoing powder can filling machine in China. With abundant experience, we warmly welcome you to buy durable chicken seasoing powder can filling machine for sale here from our factory. Quality products and reasonable price are available.
Automatic Auger filling machine with Vacuum Feeder+platform+Metal detector
Powder Filling Machine
The machine detail discription:
The machne is a new designed that we make it According to the old turnplate feeding one one side . This Auger filling within double lines has main and assist fillers . The orginanated feeding system can keep the high Proecision and Avoid the cleaning of the turntable. it can do the accurate weighting and filling work, and also could conbined with other machines to buildup a whole can -packing production line. This machine ould be used in filling mold powder ,albumne powder, condiment,dextrose,rice flour,cocoa powder,solid drink and so on.
1 Line,Dual Filler (Main filler and Assist filler)
2 Single Motor and Air Control Can's transmit
3 Two times weighing(METTLER TOLEDO), Two times fillings
4Filling control By servo Motor.
5 Suction system Machine to make the equipment Clean
6 Rejection device for the defective Can(Weight deviation)
7 Filling Height adjustable
8 Split Hopper
9 Siemens PLC and Contact Screen Control
10 The machine Enclosed By stainless steel
11 Container transmit by straight Line for easy clean
|
Model |
DH-Q3-D |
|
Dosing Mode |
Dual filler filling with online weighing |
|
Filling weight |
100-3000g |
|
Container size |
⌀60-135mm(special make 60-210mm); H 60-260mm |
|
Filling accuracy |
Filling weight 100-500g,Between ±1 Filling weight over500g, Between ±1.5-3g |
|
Filling speed |
Over 20-40Jars /min(Base 900g Powder); Over 40-50 Jars/min(Base 500g Powder) Exact speed depend the Jar size |
|
power supply |
3P,AC 208-415v 50/60HZ |
|
Total Power |
3.4 KW |
|
Air supply |
6kg/cm ,0.2CBM/MIN |
|
Total weight |
650KG |
|
Overall Dimension |
2650*1040*2330MM |
|
Hopper Volume |
50L (Main filling), 25L (assist filling) |
|
|
|
|
|
|
